Servo Stabilizer

Get a Price/Quote

MOQ : 1 Unit

Servo Stabilizer Specification

Output Current
22.7 A

Input Voltage
170V - 270V AC

Output Voltage
230V AC 1%

Efficiency
>98%

Frequency (MHz)
50 Hz

Phase
Single Phase

Current
22.7 A

Weight
Approx. 48 kg

Ambient Temperature
0C to 45C

Control System
Automatic

Usage
Industrial, Commercial, Office Equipment

Insulation Resistance
>2 Mega Ohms at 500V DC

Design
Floor Mount

Voltage Protection
Under/Overvoltage Auto Cut-off

Display
LED

Dimension (L*W*H)
540 x 330 x 430 mm

Rated Power
5 kVA

Current Type
AC to DC

Waveform Distortion
Nil

Product Type
Servo Stabilizer

Servo Stabilizer Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
100 Units Per Week

Delivery Time
7 Days

About Servo Stabilizer

With an aim to lead the market, we are persistently involved in manufacturing and supplying Servo Stabilizer. The offered product provides protection to electrical equipments against damage caused by voltage fluctuations. It is made by experienced professionals who make use of advanced electrical components and technology to obtain the end product as per the international quality standards. Owing to its fast correction ratio, longer service life and optimum performance, Servo Stabilizer has gained high appreciation in the market.

Applications:

Air conditioning plants
Pharmaceutical industries
Textile industries
Shopping malls

Efficient Voltage Regulation for Sensitive Equipment

The servo stabilizer features automatic control and precise voltage correction, supporting critical machinery in industrial and commercial settings. Its high efficiency, accuracy, and surge protection safeguard delicate devices across varying input voltages, minimizing downtime and equipment damage. The user-friendly LED display and quick response capabilities ensure smooth, uninterrupted operations.

Durable Design for Challenging Environments

Constructed with powder-coated Mild Steel and copper-wound transformers, this stabilizer is engineered for durability. Operating efficiently in humid, non-condensing conditions up to 95% RH, it meets IS 9815 / IEC 60255 standards and maintains stability at ambient temperatures from 0C to 45C. The compact floor/tabletop mounting suits diverse installation requirements.

FAQs of Servo Stabilizer:

Q: How does the servo stabilizer ensure stable output voltage for industrial or office equipment?

A: The servo stabilizer continuously monitors input voltage and automatically corrects it to maintain a stable output of 230V AC 1%. Its rapid correction speed of 35 V/sec and response time below 10 ms ensure equipment safety and consistent performance during voltage fluctuations.

Q: What is the benefit of using a copper-wound transformer in this stabilizer?

A: Copper-wound transformers provide better conductivity, higher thermal resistance, and longer service life. This design enhances efficiencyexceeding 98%and supports superior voltage regulation with minimal energy losses for demanding applications.

Q: Where can the air-cooled servo stabilizer be installed?

A: This stabilizer is suitable for floor or tabletop mounting, making it ideal for factories, commercial spaces, and office environments. Its compact design (540 x 330 x 430 mm) accommodates various installation spaces without compromising efficiency.

Q: When is surge protection and voltage cut-off activated in the stabilizer?

A: Surge protection and auto cut-off functions are triggered instantly during instances of overvoltage or undervoltage, thereby preventing potential equipment damage and reducing downtime by safely disconnecting affected circuits.

Q: What is the process for monitoring and controlling voltage fluctuations in this stabilizer?

A: The built-in automatic control system continuously scans incoming voltage, employs the copper-wound transformer for quick corrections, and updates the status on an LED display. The stabilizer ensures that output remains distortion-free and within precise limits.

Q: How does the enclosure material and design benefit long-term use in harsh environments?

A: A powder-coated Mild Steel enclosure protects internal components from corrosion, dust, and moisturemaking it highly suitable for use in humid conditions up to 95% RH. Its robust build and compliance with IS 9815 / IEC 60255 standards further ensure reliability over time.

Q: What type of appliances and equipment are ideal for use with this servo stabilizer?

A: This stabilizer is ideal for industrial machinery, commercial equipment, and sensitive office devices, especially those requiring consistent AC to DC conversion and reliable voltage protection in environments with fluctuating supply.
